599M.T5 PEACOCK
VHM-Mikro-Torusfräser für die HSC-Bearbeitung im Formenbau
| Bestell-Nr. | d1 | d2 | r | l1 | l2 | d | l | Z | In den Warenkorb |
|---|---|---|---|---|---|---|---|---|---|
| 599M.T5.0070.005.010 | 0.7 | 0.65 | 0.05 | 0.7 | 1.0 | 4.0 | 40.0 | 5 | |
| 599M.T5.0070.005.000 | 0.7 | - | 0.05 | 0.7 | 0.7 | 4.0 | 40.0 | 5 | |
| 599M.T5.0070.010.010 | 0.7 | 0.65 | 0.1 | 0.7 | 1.0 | 4.0 | 40.0 | 5 | |
| 599M.T5.0070.010.000 | 0.7 | - | 0.1 | 0.7 | 0.7 | 4.0 | 40.0 | 5 | |
| 599M.T5.0080.005.012 | 0.8 | 0.75 | 0.05 | 0.8 | 1.2 | 4.0 | 40.0 | 5 | |
| 599M.T5.0080.005.000 | 0.8 | - | 0.05 | 0.8 | 0.8 | 4.0 | 40.0 | 5 | |
| 599M.T5.0080.010.012 | 0.8 | 0.75 | 0.1 | 0.8 | 1.2 | 4.0 | 40.0 | 5 | |
| 599M.T5.0080.010.000 | 0.8 | - | 0.1 | 0.8 | 0.8 | 4.0 | 40.0 | 5 | |
| 599M.T5.0080.020.012 | 0.8 | 0.75 | 0.2 | 0.8 | 1.2 | 4.0 | 40.0 | 5 | |
| 599M.T5.0080.020.000 | 0.8 | - | 0.2 | 0.8 | 0.8 | 4.0 | 40.0 | 5 | |
| 599M.T5.0100.005.015 | 1.0 | 0.95 | 0.05 | 1.0 | 1.5 | 4.0 | 40.0 | 5 | |
| 599M.T5.0100.005.000 | 1.0 | - | 0.05 | 1.0 | 1.0 | 4.0 | 40.0 | 5 | |
| 599M.T5.0100.010.015 | 1.0 | 0.95 | 0.1 | 1.0 | 1.5 | 4.0 | 40.0 | 5 | |
| 599M.T5.0100.010.000 | 1.0 | - | 0.1 | 1.0 | 1.0 | 4.0 | 40.0 | 5 | |
| 599M.T5.0100.020.015 | 1.0 | 0.95 | 0.2 | 1.0 | 1.5 | 4.0 | 40.0 | 5 | |
| 599M.T5.0100.020.000 | 1.0 | - | 0.2 | 1.0 | 1.0 | 4.0 | 40.0 | 5 |
Artikelbeschreibung
- VHM-Mikro-Torusfräser, 5-Schneiden mit 35° Drallwinkel
- Für Bearbeitung von Stählen bis 67 HRC
- Zwischenabmessungen in 0,05-mm-Schritten
- Eingeschränkte Toleranzen (3 μm)
- Mit WAD Beschichtung
- Für Trocken- oder Nassbearbeitung
